| Performance Parameter | |
| Capacity | 28cpm |
| Carton size（L*W*H） | 140mm×140 mm×150mm（MIN）500mm×400mm×420mm（MAX） |
| Machine Size | 3000*2100*1600（L*W*H） |
| Weight | 1.7 T |
| Noise | ≤85dB |
| Main Power | 3Ph AC 380V±5% 50Hz |
| Operating Power | DC24V |
| Total Power | 5.5kw |
| Compressed Air | 0.5~0.8MPa |
| Valve Pressure | 0.4MPa |
| Glue temperature | 170℃ |
| Operator | One Person |
| Performance Parameter | |
| Capacity | 36 pcs per minute |
| Case size (L*W*H) | 230mm×150 mm×150 mm (MIN) / 400 mm×350 mm×450 mm (MAX) |
| Dimension (mm) | 2783*2770*2310 L*W*H |
| Weight | 1.9T |
| Noise | ≤85dB |
| Case Breakage Percentage | ≤0.2% |
| Main Power | 3Ph AC 380V±5% 50Hz |
| Operating Voltage | 24V DC |
| Rated Power | 7.5kW total power 1.72kW |
| Compressed Air | 0.4~0.8MPa |
| Glue Temperature | 170 C |
| Operator | 1 person |
