Roller conveyor and pack turning device. It can rotate the pack 90 ° when the pack needs to rotate 90°it is in a position of pack rotation and the block activated by the cylinder.

Two speed belt conveyor. There are two belts front and back, speed of them is different. The distance between two packs increased when pack passes the belts. 4.3Classification yard has the function of pack arranging, which can arrange the packs to needed palletizing type.

There is a device to monitor packs, and adjust the production speed according to the monitoring data.

Pallet dispenser. It can release from full pallet and collect for each single empty pallet, can store 10-15 pallets.

It can stop and alarm automatically when the machine is in a abnormal situation.

Warning signs posted, to improve the safety awareness of the operator.

Pack Type	Case	Crate	Shrink Wrapped
Dimensions	505027803930mm(LWH)
Standard Pallet Size	1100mm1100mm150mm
Power	14Kw (Including classification yard, main machine, five sections pallet conveyor, pallet dispenser, two speed belt conveyor, case rotating roller conveyor)
Compressed Air	Pressure: 0.5MPa		Air Consumption : Max: 100L /min
Weight(Main machine)	4.6 T
Floor load:	8 X 750 Kg
Horizontal angle	± 1°
Noise	≤ 85 dB

Electric Configuration
Power Supply	380V(Max.±10%)50Hz 3PH+PE
Low pressure control	SIEMENS(SHNEIDER)24VDC
Main switch	1SIEMENS(SHNEIDER)
Electromagnetic Switch	SIEMENS(SHNEIDER)
Thermomagnetic Switch	SIEMENS(SHNEIDER)
Other electric equipment protection degree no less than IP54
Electrovalve accord with ISO505599/1/0 standard
Cylinder accord with ISO 15552 – VDMA 24563-02 standard

Basic Performance Description
Capacity
Case Per Minute
Pack type	Case / Crate / Shrink Wrapped
Dimensions	505027803930mm (LWH)
Standard Pallet Size	1100mm1100mm150mm
Power	18Kw (Including classification yard,main machine, five sections pallet conveyor, pallet dispenser, two speed belt conveyor,case rotating roller convyeor)
Compressed Air	a) Pressure: 0.5MPa b) Air consumption : max 100L/min
Weight Main machine	4.6 T
Horizontal Angle	± 1°

Electric configuration
Power Supply	380V (Max.±10%) 50Hz 3PH+PE
Low Pressure Control	Low pressure control
Main Switch	SIEMENS SHNEIDER
Electromagnetic Switch	505027803930mm (LWH）
Standard Pallet Size	SIEMENS SHNEIDER
Thermomagnetic switch	SIEMENS SHNEIDER
Control System	SIEMENS
Other electric equipment protection degree no less than IP54
Electrovalve accord with ISO505599/1/0 standard
