| System Advantage |
| High efficiency, max 3000 times per hour |
| Multi-intellective fumction comtroller; |
| Reliable, innovative and multi-function application; |
| Can satisfy different palletizing mode. |
| Basic performance description | ||
| Capacity | 10800bph(500ml), 6000bph(2L) | |
| Pack Type | Shrink Wrapped | |
| Pay Load | 60KG | |
| Dimensions | 3354mm*1080mm*3993mm L*W*H | |
| Pallet Size | 1100mm*900mm*150mm | |
| Robot Power | 7.5Kw,auxiliary power : 12KW | |
| Compressed Air | Pressure: 0.5MPa | Air consumption : max 100L/min |
| Ratio of Palletizing | 99.5% | |
| Weight main machine | 1940KG, auxiliary equipment weight 2000KG | |
| Noise | ≤ 75 dB | |
| Electric configuration | |
| Power Supply | 200-220V Max.±10% 50Hz 3PH+PE |
| Low Pressure Control | SIEMENS SHNEIDER 24VDC |
| HMI | SIEMENS |
| Main Switch | 33SHNEIDER |
| Switch Button | Ø 22mm |
| Proximity Switch | Ø18mm |
| Control System | SIEMENS |
| Pneumatics | FESTO |
| Electromagnetic switch and electrovalve | FESTO |
