| Performance parameter | |
| Max Capacity | 120 pack/min |
| Packing Pattern | Thermal Shrinkage Films Only |
| Applicable Bottle Types | Glass bottles, PET bottle, pot-top cans, with a diameter between Ø 55mm to 110mm. |
| Height Of Bottles | 80mm - 320mm Attention |
| Packed Products | Length: 105mm-225mm / Width: 60mm-150mm / Height: 80mm-330mm |
| Equipment Dimension | Main machine : L12850mm*W1650mm*H2600mm |
| Bottle-Entry Belt | 3620mm Width: 730mm |
| Equipment General Power | 81.7 KW |
| Compressed Air / Pressure | 0.4-0.8Mpa / Air Consumption: 100L per Min |
| Ground load | 8 X 7500 N |
| Equipment Models | ||
| Model | NTPK-LMB35 | NTPK-LMB35 |
| Capacity(packs/min) | 35pack per minute (Film Only) | 45pack per minute (Film Only) |
| Bottle Shape | Glass Bottle & PET Bottle | Can, Glass Bottle & PET Bottle |
| Bottle Diameter | 55-110mm | 55-110mm |
| Bottle Height | 80-320mm | 80-320mm |
| Pack Size | L210~450mm/ W120~300mm/ H80~330mm | L210~450mm/ W120~300mm/ H80~330mm |
| Machine Dimension (mm) | 11270mm*1650mm*2600mm | 11270mm*1650mm*2600mm |
| Infeed Conveyor | L3600mm W730mm | L3600mm W730mm |
| Total Power | 71.5 KW | 71.5 KW |
| Control Power | 24V DC | 24V DC |
| Compressed Air | Pressure 0.4~0.8MPa Air consumption 100L/MIN |
Pressure 0.4~0.8MPa Air consumption:100L PER MIN |
| Weight | 6.5T | 6.5T |
| Floor Load | 8 X 7500 N | 8 X 7500 N |
| Noise | ≤ 85 dB | ≤ 85 dB |
