| Main Parameter | ||
| Max capacity | 80 packs/min | |
| Packing Way | carton Wrap Around | |
| Applicable Bottle | (1) Glass bottle, PET bottle, Can. Bottle diameter: Ø50~110mm (2) Bottle height: H100~300mm Attention: The plus-minus error of the diameter and height of each bottle type should be no more than 2mm, or the bottle will be counted as another type. |
|
| Packing Product | (1) Length 200~530mm (2) Width 170~320mm (3) Height 100~300mm | |
| Equipment Power Consumption | 36.5 KW | |
| Control Power Supply | 24V DC | |
| Compressed Air | (1) Pressure: 0.6 MPa | (2) Air consumption: 110L/Min |
| Performance parameter | ||||
| Capacity | 45PPM | |||
| Packing Type | Wrap Around | |||
| Applicable bottle | Glass, PET bottle and can etc. diameter ranges: Ø50~110mm | Bottle height: H70~360mm | ||
| Carton size | L200~530mm | W200~350mm | H70~360mm | |
| Bottle separating type | Servo Motor | |||
| Other Parameter | |
| Machine Size | a) Infeed conveyor : L3430mm, mat top chain width : 508mm b) Cardboard magazine : L2710mm, mat top chain width : 996mm |
| Control Power | 24V DC |
| Total Power | 23.1 Kw |
| Compressed Air | a) Pressure 0.6MPa b) Air consumption : 100L/Min 7.5 Weight: 7t |
| Equipment Models | |||
| Model | NTPK-WSDZB | ||
| Capacity (packs/min) | 45 | 60 | 80 |
| Bottle grouping mode | Servo-type | Servo-type | Servo-type |
| Dimension | 11600*2000*2660 mm | 15000*5000*2650 mm | 11600*2000*2650 mm |
| Feeding belt length | 3620mm | 3620mm | 3620mm |
| Bottle diameter | 55-100 mm | 55-100 mm | 55-100 mm |
| Bottle height | 90-300 mm | 90-300 mm | 90-300 mm |
